    HM130MAX

    • stores/8727821e9e010100ec4e836ef256c97e/products/lL0IhZIcIQO8z2HgSh6X753ywly71kgRRUdepVUM.jpg
    • stores/8727821e9e010100ec4e836ef256c97e/products/lL0IhZIcIQO8z2HgSh6X753ywly71kgRRUdepVUM.jpg
    • stores/8727821e9e010100ec4e836ef256c97e/products/sGZPBkLWcigRMTAJKtXtjb1G7am5PVSdgNjAMrt7.jpg
    • stores/8727821e9e010100ec4e836ef256c97e/products/1YcXkjY3nyqPtLani4i2eaWEm1edxbl9kxiO5oMi.jpg
    • stores/8727821e9e010100ec4e836ef256c97e/products/GKlFzt7RZzXd2icHj7Bulgc5B8j7kme80k5Jqk8l.jpg
    • stores/8727821e9e010100ec4e836ef256c97e/products/V6msxgBoAB92mh7Mi35CHZXuDbRLLWXAM7m5vkRi.jpg

    1389 $

    SELECT LOG LENGTH:

    Hurry! only 3 left in stock!

    Real time 1 visitors right now.

    00 Day
    06 hour
    54 minute
    34 second

    A wide capacity sawmill that cuts wide live edge slabs with our FULLCUT™ sawhead design, which matches a 30” (76 cm) diameter log capacity with a 30” (76 cm) throat opening, to produce stunning high-value live edge boards.

    Designed to be the most affordable and robust wide cut sawmill on the market. Its heavy-duty 4-post head design with reinforced back beam guarantees a solid foundation, driven by the included 14 HP Kohler gas powered electric start engine.

    The HM130MAX® is loaded with innovative features, including a patented automatic blade lubricant system that activates when the throttle is engaged and the RapidChange® blade system for quick blade changes without tools.

    SPECIFICATIONS

    Engine
    14 HP Manual/Electric Start Kohler

    Blade Engagement System
    Centrifugal Clutch (Gas & Go)

    Log Diameter
    30" [76 cm]

    Max Cut Width
    30" [76 cm]

    Max Board Thickness
    7" [18 cm]

    Cast Iron Bandwheel Diameter
    19" [48 cm]

    Standard Cutting Length
    10' 5" [3.1 m]

    Track Width
    37" [94 cm]

    Track Extension Length
    6' 5" [1.95 m]

    Levelling Feet
    12

    Galvanized Track Rails
    Yes

    Track Bunks
    3 x 6" [75 x 150 mm]


    Log Clamps
    2x Quick Lock

    4 Post Head Design
    Yes

    Adjustable Blade Guide
    Yes

    Blade Size
    158 x 1-1/4" [4013 x 32 mm]

    RapidChange® Blade System
    Yes

    Auto Lubrication
    Yes

    Lubricant Tank Size
    13 L [3.4 gal] Aluminum

    Hour Meter
    Yes

    Finish
    Powder Coat Paint / Galvanized Steel

    Product Weight
    921 lb [418 kg]

    Shipping Weight
    1000 lb [454 kg]
